Manufacturer floor plan
The 2619FK drawing, front wall to rear slide
The kitchen spans the front wall of Forest River's drawing, with a sink under overhead cabinets, the microwave and cooktop in the off-door corner, and a pantry in the door-side corner. Behind the kitchen, an off-door slide holds a 60-inch theater seat and the fridge; a 60-inch hide-a-bed is drawn as an option. Across from it on the door side is the 39-inch Dream Dinette, with a TV on a lift.
The bath splits across the aisle: toilet and shower on the door side, sink and linen cabinet opposite. The rear bedroom's 60 by 80 inch queen sits in its own off-door slide under overhead cabinets, a wardrobe fills the door-side rear corner, and the drawing offers a 72 by 80 inch king as an option. Two Solid Step entries, one by the kitchen and one by the bedroom, open under a 21 ft awning.
Forest River's 2027 Rockwood Ultra Lite 2619FK page and drawing →What 6,813 lb and 1,812 lb say about the 2619FK
This is a mid-pack plan on every weight measure: 5 of 11 by dry weight, 7 of 11 by hitch weight at 825 lb, and 8 of 11 by cargo carrying capacity at 1,812 lb, which is also the margin between its 8,625 lb GVWR and dry weight (7 of 9). The hitch figure is 12.1% of dry weight, the sixth lowest share of eleven. RVUSA lists two slides and sleeping for 3.
It keeps the larger 90 gal gray tank, for a 189 gal package, and stands 11 ft 3 in tall, 2 ft 3 in under a 13 ft 6 in clearance.
The layout question is where the weight goes. The kitchen, pantry, and front exterior storage bay all sit at the hitch end, and whatever is stored there adds to the published 825 lb, which is an empty-trailer figure. The rear bedroom slide, by contrast, carries mostly the bed and the overhead cabinets above it.
2619FK alternatives with the kitchen up front
Same length, two slides, sleeps 3. It is 63 lb heavier and 77 lb heavier at the hitch, with 14 lb more cargo capacity. Its front slide pairs a 67-inch theater seat with a 44-inch dinette, and the fridge moves to the door side.
Open record →Front kitchen, king at the back, lighterRockwood Ultra Lite 301FKT2 in longer and 765 lb lighter, with 675 lb more cargo capacity and a hitch weight 90 lb lower. A 72 by 80 inch king is standard across the rear, a flip-up table with folding chairs replaces the dinette, and it sleeps 2.
Open record →The shorter Rockwood with a front kitchenRockwood Mini Lite 2506FKForest River's Mini Lite 2506FK keeps a front kitchen and a rear 60 by 74 inch queen in 25 ft 10 in, 3 ft 10 in shorter. It is 1,135 lb lighter and 115 lb lighter at the hitch, carries 220 lb more cargo, and sleeps 4 with one slide, but its gray tank holds 58 gal against 90.
Open record →2619FK published figures
Checks for the 2619FK's Dream Dinette and bed slide
- Sit at the 39-inch Dream Dinette with the TV lift raised. The TV is drawn on the same door-side wall as the dinette, so check that both can be used together.
- Walk through the split bath while someone uses the shower. The sink and linen cabinet are across the aisle from the toilet and shower, so the aisle is part of the bathroom.
- If the unit has the king option, walk around it with the bed slide in. The drawing shows a 60 by 80 inch queen as standard in that slide and a 72 by 80 inch king as the option.
- Open the 60-inch theater seat's slide and check the hide-a-bed option if the unit has it, and ask the dealer where the third of RVUSA's 3 sleepers is meant to sleep.
Sources for the 2619FK record
Length, height, dry weight, hitch weight, cargo capacity, tanks, awning, and the room layout come from Forest River's 2027 Rockwood Ultra Lite 2619FK page and drawing, read on 2026-09-26. Forest River labels UVW and CCC as estimated averages based on standard build optional equipment, so the label on a given unit takes precedence. GVWR, sleeping capacity, and slide count come from RVUSA's 2027 spec guide. The Mini Lite comparison uses Forest River's 2027 Mini Lite figures as shown on that plan's record.
